QuickMount® ClickFit®
Fast & Cost-Effective Racking System
The QuickMount® ClickFit® is a fast rail-based racking system for pitched roofs that conforms to UL 2703 and UL 3741. It has been tested in extreme weather conditions and is made of robust materials, such as aluminum and coated steel, to ensure corrosion resistance and longevity.
Strength Tested
All components have been evaluated for superior structural performance.
UL 2703 & 3741 Listed
Entire system meets UL standards for solar racks, with or without MLPE devices.
Click-In Rail Assembly
The Rail Clicker integrates with ClickFit® Rails for fast and secure placement.
Class A Fire Rating
Certified to maintain the fire resistance rating of the existing roof.
PE Certified
Pre-stamped engineering letters are available in most states.
25-Year Warranty
Products guaranteed to be free of impairing defects.
Available in Design Assistant
- Comprehensive reaction forces
- Turbo-charged calculation engine
- Roof material & attachment selector
- Auto-generated documents package
QuickMount® ClickFit® Components
ClickFit® Rails come in various options for easy array designs.
• Light & Standard Sizes
• Lengths in 171.5″ & 165.4″
• Click-In Components
Tool-free, fully-bonded structural internal splice installs in seconds.
• Click-In & Tool-Free
• Fully Bonded & Structural
• Works For Both Rails
Mid Clamps simply click onto the ClickFit® Rails.
• Integrated Bonding Pins
• 30-40mm Module Heights
• Click-In Technology
End Clamps simply click onto the ClickFit® Rails.
• Integrated Bonding Pins
• 30-40mm Module Heights
• Click-In Technology
Provide an aesthetic finish to ClickFit® Rail ends.
• Optional Slide-On Caps
• Aids End Clamp Positions
• Provides Aesthetics
Rail simply clicks into L-Foot and secures with a pre-installed bolt.
• Includes Rail Clicker
• Pre-Installed Hardware
• Click-In Technology
Securely connect ClickFit® Rails and roof attachments.
• Attaches Rails & Attachments
• Rails Simply Click Into It
• Click-In Technology
Attaches and secures MLPE to the top of ClickFit® Rails.
• Goes Anywhere on Rails
• Secures MLPE Devices
• Click-In Technology
Clicks onto the top of ClickFit® Rails for wire management.
• Accommodates 1-3 PV Wires
• Installs on North or South Side
• Easily-Adjustable Tension
Secure up to four PV wires or two trunk cables in place.
• Two-Piece Construction
• Self-Piercing Screw
• Quick Installation
